FE 510 D1K1 atmospheric steel
Corten Sheet Products Description
FE 510 D1K1 corten metal sheet is a hot rolled product of structural steel in technical delivery condition with improved atmospheric corrosion resistance.
FE 510 D1K1 corten sheet is equivalent to S355J2WP (1.8946) corten steel in EN 10025 - 5 : 2004 standard and A242 Type1 corten steel material in ASTM standard and E36WA4 corten steel metal in NFA 35-502 standard.
FE 510 D1K1 corten steel sheet metal has a wide range of applications such as: construction, chimneys, manufacturing, freight cars, silos, towers and bridges.
Alloying FE 510 D1K1 corten structural steel with copper and chromium ensures a firmly adherent rust protection layer while giving it an aesthetic appearance.
FE 510 D1K1 Atmospheric Steel Products Details
FE 510 D1K1 Steel Chemical Composition
| C % | Mn % | Cr % | Si % | CEV % | S % |
| Max 0.12 | Max 1 | 0.3-1.25 | Max 0.75 | Max 0.52 | Max 0.03 |
| Cu % | P % | ||||
| 0.25-0.55 | 0.06 - 0.15 |
FE 510 D1K1 Steel Mechanical Properties
| Grade | Min. Yield Strength Mpa | Tensile Strength MPa | Impact | ||||||||
| FE 510 D1K1 | Nominal Thickness (mm) | Nominal Thickness (mm) | degree | J | |||||||
| Thick mm | ≤16 | >16 ≤40 |
>40 ≤63 |
>63 ≤80 |
>80 ≤100 |
>100 ≤150 |
≤3 | >3 ≤100 | >100 ≤150 | -20 | 27 |
| FE 510 D1K1 | 355 | 345 | …. | …. | …. | …. | 510-680 | 470-630 | …. | ||
Corten Steel Sheet Metal Products Image
GNEE Group Team Photo
GNEE Group Exhibition Pictures
GNEE Group Customer Visits
If you have more needs and questions about FE 510 D1K1 atmospheric steel, please contact us!
