A709Gr50 H Section Beam
A709Gr50 Steel Beam H
A709Gr50 high strength low alloy steel American Standard steel for bridges, also known as low alloy steel.
A709Gr50 elements on the alloy impact: alloying elements on the quenching and tempering of steel in the case of the most significant role in strengthening, because it makes full use of all the four strengthening mechanism. Quenching constitutes martensite, tempering carbide, constituting a strong second phase strengthening, together with the resistance greatly improved, so the martensite and tempering is the most economical and most useful generalized steel strengthening methods.
A709Gr50 h beam is widely used in engineering structures, such as building steel structure, construction machinery, mining machinery, trucks, bridges, pressure vessels, etc., especially for the requirements of good weldability and toughness of construction and engineering machinery components.
China h beam section Distributors--GNEE Group
A709Gr50 H Beam Profile
A709Gr50 chemical composition:
|
Grade |
C |
Si |
Mn |
P |
S |
Nb |
| A709Gr50 | ≤0.20 | ≤0.40 | ≤1.50 | ≤0.04 | ≤0.05 | 0.005～0.05 |
A709Gr50 chemical composition:
|
Grade |
Yield strength (MPa) |
Tensile strength (MPa) |
Elongation rate (A %) |
Impact force 0℃Akv J |
| A709Gr50 | ≥345 | ≥450 | ≥18 | ≥34 |
China H beam steel producers--GNEE Group
GNEE Group Receives Visiting Customers
GNEE's main products include I-beams, Angles, Channels, Carbon Steel, etc. GNEE Group has always been committed to providing high quality steel products all over the world with the tenet of "Reasonable Price, Efficient Production Time, and Excellent After-sales Service". All of our products meet international quality standards and are well received by different markets around the world.
China H steel beam producers--GNEE Group
We have on-line heavy duty H beam steel products, welcome to visit our company, if you have more needs and questions about other steel products, please feel free to contact us!
