Products Description
S235 structural steel plate is a widely used carbon structural steel grade that complies with EN 10025-2 standard. It offers a minimum yield strength of 235 MPa, a tensile strength range of 360–510 MPa, and excellent toughness and ductility.
With an elongation of ≥ 20% (measured over 200 mm), S235 steel plate provides reliable performance under stress and vibration, making it suitable for demanding engineering applications.
S235 steel plate can be easily welded, cut, bent, and riveted, supporting a broad range of fabrication processes. Typical thickness ranges from 6–150 mm, widths can reach up to 3000 mm, and lengths are available up to 12 m, with customized dimensions available upon request.
Due to these versatile properties, S235 structural steel plates are extensively used in building frameworks, bridges, machinery manufacturing, and general steel construction components, making them an essential material in both industrial and infrastructure projects.
Products Specification
| Name | Carbon Steel Sheet / Mild Steel Plate | |
| Materials |
S10C / S25C / S50C / S53C / S60C / CK45 / C50E4 / C40E4 / SS330 / SM400A / E275A / S235JR / S235JRG2 / Q235B / Q345 / A36 65Mn / 20CrMnTi 16MnCr5 4145 4340 / etc |
|
| Surface | Black / Galvanized / Zinc Coating / , etc | |
| Type | Normal / Checkered / Embossed, etc | |
| Thickness | Cold Rolled | 0.1-3mm |
| Hot Rolled | 0.1-4mm & 4-400mm | |
| Width | 600-2500mm / Customized | |
| Length | Customized Size / Cut any size as requirements | |
| Shipment Terms | EXW / FOB / CIF / CFR / CNF | |
| Payment Terms | TT / LC (must 30-50% as despoit, the balance can be paid by LC after BL), etc | |
| Export Packaging | Standard export packaging, various transportation, as customer required | |
| Application | Tyre Reinforcement / Forging Grades / Rail Steels / Spring Steels / Pre-Stressed Concrete / Wire Rope / High-strength Bars / Building / GYM, etc | |
S235JR Chemical Composition(max %)
|
Grade |
C% |
Si % |
Mn % |
P % |
S % |
N % |
Cu % |
|
S235JR |
0.23 |
- |
1.50 |
0.045 |
0.045 |
0.014 |
0.60 |
S235JR Mechanical Properties.
|
Grade |
Thickness (mm) |
Min Yield (Mpa) |
Tensile (Mpa) |
Elongation (%) |
Min Impact Energy |
|
|
S235JR |
8mm-100mm |
215Mpa-235Mpa |
360-510Mpa |
24-26% |
20 |
27J |
|
101mm-200mm |
185-195Mpa |
350-490Mpa |
22% |
20 |
27J |
|
|
201mm-400mm |
- |
- |
21% |
20 |
27J |
|
|
The min impact energy is longitudinal energy |
||||||
Products Application
S235JR is a low-carbon structural steel grade under the EN 10025 standard, widely recognized for its excellent strength, weldability, and ductility. It has a minimum yield strength of 235 MPa, a tensile strength ranging from 360 to 510 MPa, and an elongation of more than 20%, which ensures good toughness and reliability when subjected to medium loads and dynamic conditions.
In practical applications, S235JR steel is commonly used in the fabrication of structural frameworks for both industrial and residential buildings, including beams, columns, and floor supports.
It also plays an essential role in the production of components for power transmission towers, equipment bases, offshore platforms, and oil and gas structures, where stable performance under demanding environments is crucial.
Furthermore, S235JR is widely applied in highway and railway bridge construction, mechanical parts manufacturing, and welded or bolted metal structures. Thanks to its excellent machinability and cost-effectiveness, S235JR has become one of the most widely adopted materials in modern civil engineering and infrastructure projects.
Contact now to get S235JR Quote
