Product Description
Steel highfrequency welding q345 h beams i beam price philippines
1.PRODUCT SIZES
| Specification | Weight(kg/m) | Specification | Weight(kg/m) |
| 100*50*5*7 | 9.54 | 394*398*11*18 | 147 |
| 100*100*6*8 | 17.2 | 394*405*18*18 | 169 |
| 125*60*6*8 | 13.3 | 396*199*7*11 | 56.7 |
| 125*125*6.5*9 | 23.8 | 400*150*8*13 | 55.8 |
| 148*100*6*9 | 21.4 | 400*200*8*13 | 66 |
| 150*150*7*10 | 31.9 | 400*400*13*21 | 172 |
| 150*75*5*7 | 14.3 | 400*408*21*21 | 197 |
| 175*175*7.5*11 | 40.4 | 414*405*18*28 | 233 |
| 175*90*5*8 | 18.2 | 428*407*20*35 | 284 |
| 194*150*6*9 | 31.2 | 440*300*11*18 | 124 |
| 198*99*4.5*7 | 18.5 | 446*199*8*12 | 66.7 |
| 200*100*5.5*8 | 21.7 | 450*150*9*14 | 65.5 |
| 200*200*8*12 | 50.5 | 450*200*9*14 | 76.5 |
| 200*204*12*12 | 56.7 | 458*417*30*50 | 415 |
| 244*175*7*11 | 44.1 | 482*300*11*15 | 115 |
| 244*252*11*11 | 64.4 | 488*300*11*18 | 129 |
| 248*124*5*8 | 25.8 | 492*465*15*20 | 204 |
| 250*125*6*9 | 29.7 | 496*199*9*14 | 79.5 |
| 250*250*9*14 | 72.4 | 498*432*45*70 | 605 |
| 250*255*14*14 | 82.2 | 500*150*10*16 | 77.1 |
| 294*200*8*12 | 57.3 | 500*200*10*16 | 89.6 |
| 294*302*12*12 | 85 | 502*465*15*25 | 241 |
| 298*149*5.5*8 | 32.6 | 502*470*20*25 | 261 |
| 300*150*6.5*9 | 37.3 | 506*201*11*19 | 103 |
| 300*300*10*15 | 94.5 | 582*300*12*17 | 137 |
| 300*305*15*15 | 106 | 588*300*12*20 | 151 |
| 338*351*13*13 | 106 | 594*302*14*23 | 175 |
| 340*250*9*14 | 79.7 | 596*199*10*15 | 95.1 |
| 344*348*10*16 | 115 | 600*200*11*17 | 106 |
| 344*354*16*16 | 131 | 606*201*12*20 | 120 |
| 346*174*6*9 | 41.8 | 692*300*12*24 | 166 |
| 350*175*7*11 | 50 | 700*300*13*24 | 185 |
| 350*350*12*19 | 137 | 792*300*14*22 | 191 |
| 350*357*19*19 | 156 | 800*300*14*26 | 210 |
| 388*402*15*15 | 141 | 890*299*15*23 | 213 |
| 390*300*10*16 | 107 | 900*300*16*28 | 243 |
| 912*302*18*34 | 28 |
| Identification | Nominal weight 1m | Nominal dimensions | Cross-section | Dimensions for detailing | Surface | |||||||||
| kg/m | mm | A | h1 | d | Ø | pmin | pmax | AL | AG | |||||
| b | h | t1 | t2 | R1 | cm2 | mm | mm | mm | mm | m2/m | m2/m | |||
| IPE 80 | 6,0 | 46 | 80 | 3,8 | 5,2 | 5,0 | 7,64 | 69,6 | 59,6 | - | - | - | 0,328 | 54,64 |
| IPE 100 | 8,1 | 55 | 100 | 4,1 | 5,7 | 7,0 | 10,30 | 88,6 | 74,6 | - | - | - | 0,400 | 49,33 |
| IPE 120 | 10,4 | 64 | 120 | 4,4 | 6,3 | 7,0 | 13,20 | 107,4 | 93,4 | - | - | - | 0,475 | 45,82 |
| IPE 140 | 12,9 | 73 | 140 | 4,7 | 6,9 | 7,0 | 16,40 | 126,2 | 112,2 | - | - | - | 0,551 | 42,70 |
| IPE 160 | 15,8 | 82 | 160 | 5,0 | 7,4 | 9,0 | 20,10 | 145,2 | 127,2 | - | - | - | 0,623 | 39,47 |
| IPE 180 | 18,8 | 91 | 180 | 5,3 | 8,0 | 9,0 | 23,90 | 164,0 | 146,0 | M10 | 48 | 48 | 0,698 | 37,13 |
| IPE 200 | 22,4 | 100 | 200 | 5,6 | 8,5 | 12,0 | 28,50 | 183,0 | 159,0 | M10 | 54 | 58 | 0,768 | 34,36 |
| IPE 220 | 26,2 | 110 | 220 | 5,9 | 9,2 | 12,0 | 33,40 | 201,6 | 177,6 | M12 | 60 | 62 | 0,848 | 32,36 |
| IPE 240 | 30,7 | 120 | 240 | 6,2 | 9,8 | 15,0 | 39,10 | 220,4 | 190,4 | M12 | 66 | 68 | 0,922 | 30,02 |
| IPE 270 | 36,1 | 135 | 270 | 6,6 | 10,2 | 15,0 | 45,90 | 249,6 | 219,6 | M16 | 72 | 72 | 1,041 | 28,86 |
| IPE 300 | 42,2 | 150 | 300 | 7,1 | 10,7 | 15,0 | 53,80 | 278,6 | 248,6 | M16 | 72 | 86 | 1,160 | 27,46 |
| IPE 330 | 49,1 | 160 | 330 | 7,5 | 11,5 | 18,0 | 62,60 | 307,0 | 271,0 | M16 | 78 | 96 | 1,254 | 25,52 |
| IPE 360 | 57,1 | 170 | 360 | 8,0 | 12,7 | 18,0 | 72,70 | 334,6 | 298,6 | M22 | 88 | 88 | 1,353 | 23,70 |
| IPE 400 | 66,3 | 180 | 400 | 8,6 | 13,5 | 21,0 | 84,50 | 373,0 | 331,0 | M22 | 96 | 98 | 1,467 | 22,12 |
| IPE 450 | 77,6 | 190 | 450 | 9,4 | 14,6 | 21,0 | 98,82 | 420,8 | 378,8 | M24 | 100 | 102 | 1,605 | 20,69 |
| IPE 500 | 90,7 | 200 | 500 | 10,2 | 16,0 | 21,0 | 115,50 | 468,0 | 426,0 | M24 | 102 | 112 | 1,744 | 19,23 |
| IPE 550 | 106,0 | 210 | 550 | 11,1 | 17,2 | 24,0 | 134,40 | 515,6 | 467,6 | M24 | 110 | 122 | 1,877 | 17,78 |
| IPE 600 | 122,0 | 220 | 600 | 12,0 | 19,0 | 24,0 | 156,00 | 562,0 | 514,0 | M27 | ||||
1.What are the standard H-beam sizes?
H-Section Steel Beams are available in a range of sizes with widths between 4"-16" (10.2–40.6 cm), depths from 4"-16" (10.2–40.6 cm), and shared thicknesses between . 35"-. 83" (9-21 mm). H-Section Steel Beams are available in typical lengths between 8'-20' (2.44-6.1 m).
2.Which is stronger, H or I-beam?
The cross-section of a H-beam has greater strength per unit area than the I-beam. This makes the H-beam an overall stronger beam with a decent strength-to-weight ratio. As H-beams have large surface areas, they're great for carrying heavy loads.
3.What is the difference between q235b and Q345?
High Strength and Toughness
Q235 steel has a yield strength of 235 MPa (38 ksi) for thicknesses < 17mm, and a tensile strength of 375-500 MPa, whereas, Q345 steel has a yield strength of 345 MPa (50 ksi) for thicknesses < 17mm, and a tensile strength 470-630 MPa.
4.What is an H-beam used for?
H-Beam can be used in the construction of buildings due to its ability to resist tension forces in compression or shear through its sides. The property of being able to withstand both tension and compression makes it ideal for building designs that require support for vertical loads such as cables or girders.
5.Is standard for H-beam?
In India, the most commonly used sizes of H-beams are based on the Indian Standard IS 2062. The standard sizes and dimensions of H-beams in India are as follows: ISMB 100 – Width 100mm, Height 75mm, Weight 8.2kg/meter. ISMB 125 – Width 125mm, Height 75mm, Weight 12.8kg/meter.
