Inconel 718 Round Bar Stock

Inconel 718 Round Bar Stock

---

Inconel 718 alloy round bar is a nickel-based high-temperature alloy precipitated and strengthened by body-centered square γ" and face-centered cubic γ' phases. It has good comprehensive properties in the temperature range of -253~700°C, and the yield strength is below 650°C. It ranks first among deformed high-temperature alloys and has good fatigue resistance, radiation resistance, oxidation resistance, corrosion resistance, as well as good processing performance, welding performance and long-term structural stability. It can manufacture various parts with complex shapes and is used in aerospace. , nuclear energy, and petroleum industries, it has been widely used in the above temperature range.





Symbol	Element	Min %	Max %
C	Carbon	-	0.08%
Mn	Manganese	-	0.35%
Si	Silicon	-	0.35%
P	Phosphorus	-	0.015%
S	Sulfur	-	0.015%
Cr	Chromium	17.00%	21.00%
Ni	Nickel	50.00%	55.00%
Mo	Molybdenum	2.80%	3.30%
Cb (Nb)	Columbium (Niobium)	4.75%	5.50%
Ti	Titanium	0.65%	1.15%
Al	Aluminum	0.20%	0.80%
Co	Cobalt	-	1.00%
B	Boron	-	0.006%
Cu	Copper	-	0.30%
Pb	Lead	-	0.0005% (5 ppm)
Bi	Bismuth	-	0.00003% (0.3 ppm)
Fe	Iron	remainder	-





Sample Orientation per Diameter or Least Distance between Parallel Sides	Tensile Strength	Yield Strength 0.2% Offset	Elongation in 4D	Reduction of Area
Longitudinal Size 10" and under	185 ksi	150 ksi	12%	15%
Long Transverse Forgings 5" and under	180 ksi	150 ksi	10%	12%
Long Transverse Forgings Over 5" & ≤ 10"	180 ksi	145 ksi	10%	12%
Transverse Bars 5" and under	180 ksi	150 ksi	6%	8%
Transverse Bars Over 5" & ≤ 10"	180 ksi	145 ksi	6%	8%





Sample Orientation per Diameter or Least Distance between Parallel Sides	Tensile Strength	Yield Strength 0.2% Offset	Elongation in 4D	Reduction of Area
Longitudinal Size 5" and under	145 ksi	125 ksi	12%	15%
Longitudinal Size over 5% and ≤ 10"	145 ksi	122 ksi	12%	15%
Long Transverse Forgings 5" and under	140 ksi	125 ksi	10%	12%
Long Transverse Forgings Over 5" & ≤ 10"	140 ksi	122 ksi	10%	12%
Transverse Bars 5" and under	140 ksi	125 ksi	6%	8%
Transverse Bars Over 5" & ≤ 10"	140 ksi	122 ksi	6%	8%





Inconel 718 alloy round bars are mainly used to manufacture various stationary and rotating parts in aviation and aerospace engines, such as discs, rings, casings, shafts, blades, fasteners, elastic elements, gas ducts, sealing elements, etc. Welding structural parts; manufacturing various elastic elements and grids for use in the nuclear energy industry; manufacturing parts and other parts for applications in the petroleum and chemical industries.













We have enough Inconel 718 Round Bar Stock in stock, and we can also customize it according to your needs.
